Technische Daten

• Nominal Voltage Uo/U 1.0/1.0 kV AC – 1.5/1.5 kV DC
• Test Voltage 6.5 kV AC
• Operating Temperature -40°C up to +90°C
• Max. Core Temperature +120°C (for 20.000 hrs.)
• Min. Bending Radius 5 x cable diameter (fixed installation)
• CPR Dca-s2,d2,a1
• Approval TÜV Rheinland
• Standards EN 50618:2014, IEC 60228, EN 50395, EN 50396, EN 60332-1-2, EN 61034-1/2, EN 50525-1, EN 60216-1/2
